DOOSAN PUMA TT2500SY 2010
- Condition: used
- published: 08/10/2025
- 25IND47399
Technical data
- Condition: used
- Year: 2010
Description
USED REFURBISHED TO LIKE-NEW CONDITION.
DOOSAN PUMA TT 2500SY, used and fully refurbished to like-new condition, completely overhauled both mechanically and electronically, in perfect working order.
...
USED REFURBISHED TO LIKE-NEW CONDITION.
DOOSAN PUMA TT 2500SY, used and fully refurbished to like-new condition, completely overhauled both mechanically and electronically, in perfect working order.
USED – REFURBISHED TO LIKE-NEW CONDITION.
DOOSAN PUMA TT 2500SY, used and fully refurbished to like-new condition, completely overhauled both mechanically and electronically, in perfect working order.
DOOSAN TT 2500 SY lathe data sheet - 2010
Main technical features - Technical Details
Spindle diameter: 210 mm
Maximum workable diameter: Machinable: 390 mm upper turret - 300 mm lower turret
Maximum diameter above the bench: 800 mm
Spindle mount: A8 - Chuck diameter: 250 mm
Maximum machinable length: 700 mm
Spindle hole: 76 mm
Maximum spindle RPM: 3500 rpm
Spindle motor power: 26 kW - 26 kW
Driven tool speed (upper and lower): 4000 rpm
Driven tool power spindle: 5.5 kW
Tool diameter (upper and lower): 40 mm
Machine floor space: 5000 x 2210
Machine height: 2330
Machine weight: 11,700 kg
Z1-Z2 axis stroke: 255-190
X1-X2 axis stroke: 800-900
Y-B axis stroke: 120-810
Included equipment
• Chip conveyor
• Coolant tank
• Fume extraction system
• 3 straight motorized tools, 3 90° tools
• Fixed tool holders
Working
Revised
Under warranty
CE compliant
