DOOSAN PUMA 300 M 2009
- Condition: used
- published: 08/10/2025
- 25IND47401
Technical data
- Condition: used
- Year: 2009
Description
USED REFURBISHED TO LIKE-NEW CONDITION.
DOOSAN PUMA 300 M, used and fully refurbished to like-new condition, completely overhauled both mechanically and electronically, in perfect working order.
USED ...
USED REFURBISHED TO LIKE-NEW CONDITION.
DOOSAN PUMA 300 M, used and fully refurbished to like-new condition, completely overhauled both mechanically and electronically, in perfect working order.
USED – REFURBISHED TO LIKE-NEW CONDITION.
DOOSAN PUMA 300 M, used and fully refurbished to like-new condition, completely overhauled both mechanically and electronically, in perfect working order.
Main Technical Details
Maximum rotating diameter over the bed: 670 mm / Maximum rotating diameter over the carriage: 450 mm
Spindle mount: A11 / Chuck diameter: 315 mm / 170 mm
Maximum machinable length: 565 mm
Spindle hole: 102 mm
Maximum spindle RPM: 3000 rpm - 4500 rpm
Spindle motor power: 22 kW - 7.5 kW
Driven tool speed (upper and lower) / Driven tool speed: 4000 rpm
Driven tool power spindle: 5.5 kW
Tool mount: BMT 65
Machine floor space: 3630 x 1730
Machine height: 1830
Machine weight: 5800 kg
Z1-axis stroke: 680 mm
X1-axis stroke: 250 mm
B-axis stroke: 680 mm
Included accessories:
• Automatic door opening
Working
Revised
Under warranty
CE compliant
