GLEASON-PFAUTER P1200 G 1998
- Condition: used
- published: 16/10/2025
- 25IND47595
Technical data
- Condition: used
- Year: 1998
Description
CNC profile grinder for cylindrical gears GLEASON_PFAUTER P1200G, control SINUMERIK 840C, built in 1998, workpiece diameter 1200 mm, max. radial travel 770 mm,
max, tangential travel 300 mm, max. a ...
CNC profile grinder for cylindrical gears GLEASON_PFAUTER P1200G, control SINUMERIK 840C, built in 1998, workpiece diameter 1200 mm, max. radial travel 770 mm,
max, tangential travel 300 mm, max. axial travel 700 mm, lowest grindign wheel position above table 470 mm, max priofile depth 80 mm, grindign spindle swivel angle
+/- 45 degrees, oute diamter 800 mm, bore diameter x depth Ø 300 x 900 mm, max table size 10to, drive power 24 kW, grinding arbor Ø 80 mm, counter holder,
nc dressing unit.
