AERZEN GM 50 L DN 150 2015
- Condition: used
- published: 07/11/2025
- 25IND48057
Technical data
- Condition: used
- Year: 2015
Description
Technical performance data:
Intake gas: Air
Volume at intake conditions Q1 - 42.5 m3/min
Density at intake conditions – 2550 m3/h
Suction pressure (absolute) – p1 1.00 bar
Differential pressure ...
Technical performance data:
Intake gas: Air
Volume at intake conditions Q1 - 42.5 m3/min
Density at intake conditions – 2550 m3/h
Suction pressure (absolute) – p1 1.00 bar
Differential pressure – Δp – 123 mbar
Discharge pressure (absolute) – p2 - 1.12 bar
Suction temperature - t1 – 20.0 °C
Discharge temperature - t2 – 31.0 °C
Blower speed - nG – 2800 rpm
Motor speed - nm – 2945 rpm
Shaft power consumption - PK – 14.8 kW
Tolerances for flow rate and shaft power
Installed power - PM – 18.5 kW ± 5%
Noise Level
With cab – 68 dB(A) - tolerance ± 2 dB
Without cab – 91 dB(A) - according to DIN 45 635
Includes:
IEC-standard electric motor, efficiency class: IE3
Only for 400V-50Hz and 460V-60Hz
PAINTED soundproof cabin
External cabin oil level indicator (except GM3S)
Mechanical cooling fan
Pressure gauge
Filter clogging indicator
Truck packaging, ISPM15 wood
Maintenance kit with initial oil fill
Working
CE compliant
