WELE AA1480#50 2011
- Condition: used
- published: 29/05/2026
- 26IND49132
Technical data
- Condition: used
- Year: 2011
- X-axis travel: 1001/2000 mm
Description
CNC: FANUC 18iM
Table
Table dimensions: 1550x800 mm
Maximum allowable weight: 1800 kg
Capacity
Longitudinal X-axis travel: 1400 mm
Transversal Y-axis travel: 800 mm
Vertical Z-axis travel: 700 mm
Spin ...
CNC: FANUC 18iM
Table
Table dimensions: 1550x800 mm
Maximum allowable weight: 1800 kg
Capacity
Longitudinal X-axis travel: 1400 mm
Transversal Y-axis travel: 800 mm
Vertical Z-axis travel: 700 mm
Spindle
Spindle mount: BT50 ISO
Rotation speed: 6000 rpm
Motor power: 18-22 kW
Feed rates
Rapid X, Y, Z axes: 24000/24000/20000 mm/min
Tool magazine
Tool stations: 30
Specific Properties
Distance between table top and spindle nose: 200-900 mm
Distance between table and floor: 980 mm
Max. torque: 626/740 Nm
Positioning accuracy: 0.015 mm
Repeatability: 0.008 mm
With three internal augers, chip conveyor, and air/water valve through the spindle.
Working
