PINSK KB8336 1982
- Condition: used
- published: 27/06/2026
- 26IND49316
Technical data
- Condition: used
- Year: 1982
Description
Knuckle Joint Coining Press KB8336
Manufacturer: Pinsk
Year: 1982
Technical data
• Press force: 400 tf (4000 kN)
• Slide stroke: 130 mm
• Stroke rate: 50 spm
• Maximum shut height: ...
Knuckle Joint Coining Press KB8336
Manufacturer: Pinsk
Year: 1982
Technical data
• Press force: 400 tf (4000 kN)
• Slide stroke: 130 mm
• Stroke rate: 50 spm
• Maximum shut height: 475 mm
• Slide adjustment: 12 mm
• Table size: 500 × 500 mm
• Bolster plate thickness: 100 mm
Lower ejector
• Stroke: 80 mm
• Force: 12 tf
Upper ejector
• Stroke: 10 mm
• Force: 4 tf
Main motor
• Power: 19 kW
• Speed: 940 rpm
Overall dimensions: 1980 × 1240 × 2800 mm
Weight: 8500 kg
