CMT URSUS 300
- Condition: used
- published: 30/10/2026
- 26IND49898
Technical data
- Condition: used
- Year: undefined
Description
Center height above bed: 300 mm
Distance between centers: 3000 mm
Bar passage: 105 mm
Spindle nose: CL 8"
Spindle reduction bushing: Morse taper no. 5 MK5
Maximum diameter allowed above bed: 600 mm
Ma ...
Center height above bed: 300 mm
Distance between centers: 3000 mm
Bar passage: 105 mm
Spindle nose: CL 8"
Spindle reduction bushing: Morse taper no. 5 MK5
Maximum diameter allowed above bed: 600 mm
Maximum turning diameter on carriage: 380 mm
Cross slide travel: 350 mm
Tool carriage travel: 170 mm
Bed width: 330 mm
Cross slide width: 250 mm
Maximum turning diameter in the cavity: 810 mm
Permitted steady rest diameter: 60 ÷ 235 mm
Permitted steady rest diameter: 10 ÷ 114 mm
Sub-tail quill diameter: 68 mm
Quilt travel: 200 mm
Tailstock taper: CM 5
Main motor power 7.5 kW
Spindle speed: Continuously variable, 2 ranges
Spindle speed range: 35 to 1500 rpm
Working
