ROSA HBO
- Condition: used
- published: 30/10/2026
- 26IND49913
Technical data
- Condition: used
- Year: undefined
Description
DRILLING CAPACITY
Maximum diameter in steel: 16 mm
Maximum hole diameter in cast iron: 23 mm
Hole depth: 110 mm
SPINDLES
Number of speeds: 6
Revolutions per minute with 42-speed motor: 380 – 760 – ...
DRILLING CAPACITY
Maximum diameter in steel: 16 mm
Maximum hole diameter in cast iron: 23 mm
Hole depth: 110 mm
SPINDLES
Number of speeds: 6
Revolutions per minute with 42-speed motor: 380 – 760 – 850 – 1700 – 2100 – 4200
Revolutions per minute with 50-speed motor: 450 – 900 – 1000 – 2000 – 2500 – 5000
Morse taper N 2
DIMENSIONS
Vertical movement of the spindle head 130 mm
Maximum distance between table and spindle 550 mm
Minimum distance between table and spindle 90 mm
Vertical movement of the table 350 mm
MACHINE CONTROL
Motor speed (at 42 rpm) 1200/2400
Motor power per spindle hp 0.7/0.9
TABLE
Number of spindles: 1
Working surface: 300x300 mm
Width of T-slots: 12 mm
WEIGHTS AND OVERALL DIMENSIONS
Weight: 300 kg
Overall dimensions: 650x610x1890 mm
